Water Pump Motors

Water Pump Motors

  • Our range of water pump motors can be used in various scenarios, including swimming pool, submersible, pressure, cooling, and oxygenation pumps.
  • These motors have high starting torques and deliver good overload capacity, high efficiency, and low temperature rise.
  • All our motor bases comply with IEC and NEMA specifications, or may be customized.
Get a Quote
Product Information
Model Rated Voltage (V) Frequency (Hz) Output Power (W) Current (A) Rated Speed (r/min) Starting Torque (N.m) Max. Torque (N.m) Connected Capacitor (μF/V)
YYD-90L-2 220 50 2200 13.65 2800 1.85 10.5 35/450
YYD-90L-2S 380 50 2200 3.6 2900 15 19.5
YYD-90S-2 220 50 1500 9 2800 1.5 8.5 30/450
YYD-90S-2S 380 50 1500 2.85 2900 10 11.2
YYD-8042B 220 50 1200 5.35 2850 1 6 25/450
YYD-8032B 220 50 750 4.1 2850 1 5 25/450
YYD-8022B 220 50 550 3.2 2830 0.55 2.5 20/450
YYD-250 220 50 250 1.6 2750 0.35 1.29 6/450
YYB-0.5HP-4 230 50 250 1.6 2750 0.35 1 8/450
YYB-0.5HP-4B 380 (1PH) 50 250 0.6 2750 0.35 1 5/600
YYB-0.5HP-4BB 110/220 50/60 250 3.4/1.7 2750/3340 0.35 1 28/250
YYB-0.5HP-4C 110 60 250 3.4 3340 0.35 1 28/250
YYB-0.5HP-4DD 220/440 50/60 250 1.7/0.8 2750/3340 0.35 1 8/450
561001JA 230 60 750 4.5 3400 1 3.9 20/450
561501JA 230 60 1100 6.4 3400 1.1 5.4 25/450
562001JA 230 60 1500 8.8 3400 1.2 6.4 30/450
561002JA Two-speed 230 60 750/120 4.5/2.1 34500/1750 0.9/1.2 3.9 35/450
561502JA Two-speed 230 60 1100/150 6.5/2.4 3400/1750 1/1.6 5.4/1.2 35/450
562002JA Two-speed 230 60 1500180 8.6/3.1 3400/1750 1.2/2.4 7/1.5 60/300
561001JD dual-voltage 115/20-230 60 750 9.2/4.6 3400 0.9 3.2 60/300
561501JD dual-voltage 115/208-230 60 1100 13/6.5 3400 1.1 4.8 60/300
562001JD dual-voltage 115/230 60 1350 16.4/8.2 3450 1.2 5.8
480501JC 115 60 370 7.5 3450 0.7 2
480751JC 115 60 550 9.5 3450 0.8 2.5
481001JC 115 60 750 11 3450 1.3 3.2
480752JC Two-speed 115 60 550/ 90 10月3日 3450/1750 0.8 2.5
481002JC Two-speed 115 60 750/120 10.5/3.3 3450/1750 1.3 3.2

Get A Quote​

We offer professional, high-quality, fast production and processing services, as well as ODM/OEM services, covering all those from product R&D, design, manufacturing, to post-production maintenance.
